CHF2Br |
|
PDF |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Bromine |
|
|
|
Nuclear
Quadrupole Coupling Constants |
|
|
|
in
Bromodifluoromethane |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Bromine nqcc's in
bromodifluoromethane were determined by Ogata et al. [1], who also
derived an effective ro molecular structure.
Calculation
of the nqcc's was made here on this structure, on an ~re structure given by
MP2/aug-cc-pVTZ optimization with empirically corrected CBr, CCl, and
CF bond lengths, and on an ab
initio (a.i.) re structure derived by Charmet et al.
[2] by CCSD(T) method in conjunction with a hierarchical series of
correlation consistent bases extrapolated to CBS. Calculated and
experimental nqcc's are
compared in Tables 1 and 2.
Structure parameters are given in Table 5. |
|
|
|
|
|
|
|
|
|
|
|
|
In Tables 3 and 4, the results are
shown of calculation on a CCSD(T)/cc-pCVQZ ab initio structure derived by
Cazzoli et al. [3]. Also shown in these Tables are the results of
calculation of the nqcc's made at the CCSD(T)/cc-pCVQZ level of theory
with relativistic and vibrational corrections [3]. These are
compared with the experimental nqcc's of Cazzoli et al. [3]. |
|
|
|
|
|
|
|
|
|
|
|
|
In Tables 1 - 4, the
subscripts
a,b,c refer to the principal axes of the inertia tensor. Subscripts
x,y,z refer to the principal axes of the nqcc tensor.
The nqcc y-axis is chosen coincident with the b-axis. These are
perpendicular to the symmetry plane of the molecule. Ø
(degrees) is the angle between its subscripted parameters. ETA = (Xxx - Xyy)/Xzz. |
|
|
RMS is the root mean square
difference between calculated and experimental diagonal nqcc
(percentage of average of absolute experimental nqcc's).
RSD
is the residual standard deviation of the calibration of the
computional model for calculation of the nqcc's, which may be
taken as
an estimate of the uncertainty in the calculated nqcc's. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| |
|
|
|
|
|
|
|
|
|
|
|
Table 1. 79Br nqcc's in CHF2Br
(MHz). Calculation was made on ro, ~re,
and a.i. re [2] structures. |
|
| |
|
|
|
|
|
|
|
|
|
|
|
|
|
Calc / ro |
|
Calc / ~re |
|
Calc / a.i. re |
|
Expt. [1] |
|
| |
|
|
|
|
|
|
|
|
|
|
|
Xaa |
|
530.28 |
|
523.75 |
|
524.54 |
|
521.28(9) |
|
|
Xbb |
- |
282.62 |
- |
280.32 |
- |
280.78 |
- |
279.80(6) |
|
|
Xcc |
- |
247.66 |
- |
243.43 |
- |
243.76 |
- |
241.48 |
|
|
|Xac| |
|
183.87 |
|
183.02 |
|
182.77 |
|
187.1(26) |
|
|
|
|
|
|
|
|
|
|
|
|
|
RMS |
|
6.58 (1.9 %) |
|
1.84 (0.53 %) |
|
2.37 (0.68 %) |
|
|
|
|
RSD |
|
1.58 (0.39 %) |
|
1.58 (0.39 %) |
|
1.58 (0.39 %) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Xxx |
- |
288.93 |
- |
284.86 |
- |
285.02 |
- |
284.9(23) |
|
|
Xyy |
- |
282.62 |
- |
280.32 |
- |
280.78 |
- |
279.80(6) |
|
|
Xzz |
|
571.55 |
|
565.18 |
|
565.80 |
|
564.7(23) |
|
|
ETA |
- |
0.011 |
- |
0.0080 |
- |
0.0075 |
- |
0.009(4) |
|
|
Øz,a |
|
12.6 |
|
12.75 |
|
12.72 |
|
13.1(3) |
|
|
Øa,CBr |
|
12.5 |
|
12.48 |
|
12.46 |
|
|
|
|
Øz,CBr |
|
0.1 |
|
0.27 |
|
0.26 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| |
|
|
|
|
|
|
|
|
|
|
|
Table 2. 81Br nqcc's in CHF2Br
(MHz). Calculation was made on ro, ~re, and
a.i. re [2] structures. |
|
| |
|
|
|
|
|
|
|
|
|
|
|
|
|
Calc / ro |
|
Calc / ~re |
|
Calc / a.i. re |
|
Expt. [1] |
|
| |
|
|
|
|
|
|
|
|
|
|
|
Xaa |
|
443.09 |
|
437.64 |
|
438.30 |
|
435.61(10) |
|
|
Xbb |
- |
236.12 |
- |
234.20 |
- |
234.58 |
- |
233.84(6) |
|
|
Xcc |
- |
206.97 |
- |
203.44 |
- |
203.71 |
- |
201.76 |
|
|
|Xac| |
|
153.49 |
|
152.79 |
|
152.57 |
|
148.5(29) |
|
|
|
|
|
|
|
|
|
|
|
|
|
RMS |
|
5.42 (1.9 %) |
|
1.53 (0.53 %) |
|
1.96 (0.68 %) |
|
|
|
|
RSD |
|
1.38 (0.40 %) |
|
1.38 (0.40 %) |
|
1.38 (0.40 %) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Xxx |
- |
241.39 |
- |
237.99 |
- |
238.13 |
- |
234.6(25) |
|
|
Xyy |
- |
236.12 |
- |
234.20 |
- |
234.58 |
- |
233.84(6) |
|
|
Xzz |
|
477.51 |
|
472.19 |
|
472.71 |
|
468.5(25) |
|
|
ETA |
- |
0.011 |
- |
0.0080 |
- |
0.0075 |
- |
0.002(5) |
|
|
Øz,a |
|
12.6 |
|
12.74 |
|
12.71 |
|
12.5(4) |
|
|
Øa,CBr |
|
12.5 |
|
12.47 |
|
12.45 |
|
|
|
|
Øz,CBr |
|
0.1 |
|
0.27 |
|
0.26 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| |
|
|
|
|
|
|
|
|
|
|
Table 3. 79Br nqcc's in CHF2Br
(MHz). Calculation was made on the a.i. re [3]
structure. |
|
| |
|
|
|
|
|
|
|
|
|
|
|
|
|
Calc |
|
Calc [3] |
|
Expt. [3] |
|
| |
|
|
|
|
|
|
|
|
|
|
79Br |
Xaa |
|
522.94 |
|
521.353 |
|
521.257(9) |
|
|
|
Xbb |
- |
279.68 |
- |
279.659 |
- |
279.804(40) |
|
|
|
Xcc |
- |
243.27 |
- |
241.694 |
- |
241.453(40) |
|
|
|
|Xac| |
|
181.57 |
|
183.963 |
|
185.87(28) |
|
|
|
|
|
|
|
|
|
|
|
|
|
RMS |
|
1.43 (0.41 %) |
|
0.172 (0.05 %) |
|
|
|
|
|
RSD |
|
1.58 (0.39 %) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Xxx |
- |
284.11 |
|
|
|
|
|
|
|
Xyy |
- |
279.68 |
|
|
|
|
|
|
|
Xzz |
|
563.79 |
|
|
|
|
|
|
|
ETA |
- |
0.0079 |
|
|
|
|
|
|
|
Øz,a |
|
12.68 |
|
|
|
|
|
|
|
Øa,CBr |
|
12.45 |
|
|
|
|
|
|
|
Øz,CBr |
|
0.23 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| |
|
|
|
|
|
|
|
|
|
|
Table 4. 81Br nqcc's in CHF2Br
(MHz). Calculation was made on the a.i. re [3]
structure. |
|
| |
|
|
|
|
|
|
|
|
|
|
|
|
|
Calc |
|
Calc [3] |
|
Expt. [3] |
|
| |
|
|
|
|
|
|
|
|
|
|
81Br |
Xaa |
|
436.96 |
|
435.628 |
|
435.521(10) |
|
|
|
Xbb |
- |
233.66 |
- |
233.644 |
- |
233.701(32) |
|
|
|
Xcc |
- |
203.30 |
- |
201.984 |
- |
201.820(32) |
|
|
|
|Xac| |
|
151.57 |
|
153.567 |
|
155.210(89) |
|
|
|
|
|
|
|
|
|
|
|
|
|
RMS |
|
1.19 (0.41 %) |
|
0.118 (0.04 %) |
|
|
|
|
|
RSD |
|
1.58 (0.39 %) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Xxx |
- |
237.37 |
|
|
|
|
|
|
|
Xyy |
- |
233.66 |
|
|
|
|
|
|
|
Xzz |
|
471.03 |
|
|
|
|
|
|
|
ETA |
- |
0.0079 |
|
|
|
|
|
|
|
Øz,a |
|
12.67 |
|
|
|
|
|
|
|
Øa,CBr |
|
12.44 |
|
|
|
|
|
|
|
Øz,CBr |
|
0.23 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| |
|
|
|
|
|
|
|
|
|
| Table 5. CHF2Br
Structure parameters, ro [2], ~re,
and a.i. re [2,3] (Å
and degrees). |
| |
|
|
|
|
|
|
|
|
|
|
|
ro |
~re |
a.i.
re [2] |
a.i. re
[3] |
|
|
|
|
|
|
|
|
|
|
| CBr |
|
1.908(15) |
1.9258 |
1.9355 |
1.9275 |
| CF |
|
1.347(11) |
1.3359 |
1.3358 |
1.3343 |
| CH |
|
1.098 |
1.0849 |
1.0854 |
1.0842 |
| BrCH |
|
110.8 |
109.02 |
108.44 |
108.60 |
| BrCF |
|
110.6(8) |
109.77 |
109.55 |
109.71 |
| FCF |
|
107.4(1) |
108.22 |
108.45 |
|
| HCF |
|
|
|
|
|
|
|
110.21 |
|
|
|
|
|
|
|
|
|
|
| Z-Matrix |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| H |
|
|
|
|
|
|
|
|
|
| C |
1 |
R2 |
|
|
|
|
|
|
|
| Br |
2 |
R3 |
1 |
A3 |
|
|
|
|
|
| F |
2 |
R4 |
3 |
A4 |
1 |
D |
|
|
|
| F |
2 |
R4 |
3 |
A4 |
1 |
- D |
|
|
|
| |
|
|
|
|
|
|
|
|
|
|
ro |
~re |
a.i. re
[2] |
a.i. re
[3] |
|
|
|
|
|
|
|
|
|
|
|
|
| R2 = 1.098 |
1.0849 |
1.0854 |
1.0842 |
|
|
| R3 = 1.908 |
1.9258 |
1.9355 |
1.9275 |
|
|
| R4 = 1.347 |
1.3359 |
1.3358 |
1.3343 |
|
|
| A3 = 110.8 |
109.024 |
108.44 |
108.60 |
|
|
| A4 = 110.6 |
109.7735 |
109.55 |
109.71 |
|
|
| D = 120.5735 |
120.4292 |
120.5765 |
120.51401 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
[1] T.Ogata, S.Kuwano, and S.Oe,
J.Mol.Spectrosc. 185,147(1997). |
|
|
[2] A.P.Charmet, P.Stoppa,
N.Tasinato, A.Baldan, S.Giorgianni, and A.Gambi, J.Chem.Phys.
133,044310(2010). |
|
|
[3] G.Cazzoli, L.Cludi, C.Puzzarini,
P.Stoppa, A.Pietropolloi Charmet, N.Tasinato, A.Baldacci, A.Baldan,
S.Giorgianni, R.Wugt Larsen, S.Stopkowicz, and J.Gauss, J.Physical
Chemistry A, 115,453(2011). |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
