(CH3)2C2H2S
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Sulfur
|
|
|
Nuclear
Quadrupole Coupling Constants |
|
|
|
in trans-2,3-Dimethylthiirane |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
The diagonal components of the nqcc tensor for 33S in t-2,3-dimethylthiirane were determined by Grabow and Dreizler [1]. Heavy atom rs and ro structures were determined by Hartwig and Dreizler [2]. Calculation of the
nqcc tensor was made here on these structures, each with CH parameters
determined by MP2/6-31G(d,p) and MP2/6-311+G(d,p) partial optimization.
|
|
|
Calculated and experimental nqcc
tensors are compared in Tables 1 - 4. Structure parameters are
given in Table 5. |
|
|
|
|
|
|
|
|
|
|
|
|
In Tables 1 - 4, subscripts a,b,c refer to the principal axes of the inertia
tensor, subscripts x,y,z to the principal axes of the nqcc tensor. Ø (degrees)
is the angle between its subscripted parameters. ETA = (Xxx
- Xyy)/Xzz. |
|
|
RMS is the root mean square
difference between calculated and experimental nqcc's (percentage of
average experimental nqcc). RSD is the residual standard deviation
of calibration of the model for calculation of
the nqcc's. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| |
|
|
|
|
|
|
|
|
|
Table 1. 33S nqcc's in t-2,3-Dimethylthiirane (MHz). Calculation was made on the ro structure with CH parameters given by MP2/6-31G(d,p) partial optimization. |
|
| |
|
|
|
|
|
|
|
|
|
|
|
Calc [a] B3LYP/6-311G(3df,3p) model. |
|
|
|
|
Calc [b] B3LYP/TZV+(3df,3p) model. |
|
|
|
|
|
|
|
|
|
|
|
|
|
Calc. [a]
|
|
Calc. [b] |
|
Expt. [1] |
|
| |
|
|
|
|
|
|
|
|
|
Xaa |
|
8.45 |
|
8.42 |
|
8.3871(93) |
|
|
Xbb |
- |
32.90 |
- |
32.88 |
- |
32.3291(174) |
|
|
Xcc |
|
24.45 |
|
24.46 |
|
23.9420(174) |
|
|
|Xac| |
|
29.07 |
|
29.12 |
|
|
|
|
|
|
|
|
|
|
|
|
|
RMS |
|
0.44 (2.1 %) |
0.44 (2.0 %) |
|
|
|
RSD |
|
0.39 (1.7 %) |
0.35 (1.5 %) |
|
|
|
|
|
|
|
|
|
|
|
|
Xxx |
- |
13.70 |
- |
13.77 |
|
|
|
|
Xyy |
- |
32.90 |
- |
32.88 |
|
|
|
|
Xzz |
|
46.61 |
|
46.65 |
|
|
|
|
ETA |
|
0.412 |
|
0.410 |
|
|
|
|
Øz,a |
|
52.69 |
|
52.70 |
|
|
|
|
Øa,n* |
|
54.45 |
|
54.45 |
|
|
|
|
Øz,n |
|
1.76 |
|
1.75 |
|
|
|
|
Øy,bi* |
|
0 |
|
0 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
* n is normal to CSC-plane, bi is bisector of CSC-angle.
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| |
|
|
|
|
|
|
|
|
|
Table 2. 33S nqcc's in t-2,3-Dimethylthiirane (MHz). Calculation was made on the ro structure with CH parameters given by MP2/6-311+G(d,p) partial optimization. |
|
| |
|
|
|
|
|
|
|
|
|
|
|
Calc [a] B3LYP/6-311G(3df,3p) model. |
|
|
|
|
Calc [b] B3LYP/TZV+(3df,3p) model. |
|
|
|
|
|
|
|
|
|
|
|
|
|
Calc. [a]
|
|
Calc. [b] |
|
Expt. [1] |
|
| |
|
|
|
|
|
|
|
|
|
Xaa |
|
8.36 |
|
8.33 |
|
8.3871(93) |
|
|
Xbb |
- |
32.94 |
- |
32.92 |
- |
32.3291(174) |
|
|
Xcc |
|
24.58 |
|
24.58 |
|
23.9420(174) |
|
|
|Xac| |
|
29.02 |
|
29.07 |
|
|
|
|
|
|
|
|
|
|
|
|
|
RMS |
|
0.51 (2.4 %) |
0.50 (2.3 %) |
|
|
|
RSD |
|
0.39 (1.7 %) |
0.35 (1.5 %) |
|
|
|
|
|
|
|
|
|
|
|
|
Xxx |
- |
13.66 |
- |
13.72 |
|
|
|
|
Xyy |
- |
32.94 |
- |
32.92 |
|
|
|
|
Xzz |
|
46.60 |
|
46.64 |
|
|
|
|
ETA |
|
0.414 |
|
0.412 |
|
|
|
|
Øz,a |
|
52.81 |
|
52.81 |
|
|
|
|
Øa,n* |
|
54.44 |
|
54.44 |
|
|
|
|
Øz,n |
|
1.63 |
|
1.63 |
|
|
|
|
Øy,bi* |
|
0 |
|
0 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| |
|
|
|
|
|
|
|
|
|
Table 3. 33S nqcc's in t-2,3-Dimethylthiirane (MHz). Calculation was made on the rs structure with CH parameters given by MP2/6-31G(d,p) partial optimization. |
|
| |
|
|
|
|
|
|
|
|
|
|
|
Calc [a] B3LYP/6-311G(3df,3p) model. |
|
|
|
|
Calc [b] B3LYP/TZV+(3df,3p) model. |
|
|
|
|
|
|
|
|
|
|
|
|
|
Calc. [a]
|
|
Calc. [b] |
|
Expt. [1] |
|
| |
|
|
|
|
|
|
|
|
|
Xaa |
|
9.25 |
|
9.21 |
|
8.3871(93) |
|
|
Xbb |
- |
33.18 |
- |
33.15 |
- |
32.3291(174) |
|
|
Xcc |
|
23.93 |
|
23.94 |
|
23.9420(174) |
|
|
|Xac| |
|
28.86 |
|
28.91 |
|
|
|
|
|
|
|
|
|
|
|
|
|
RMS |
|
0.70 (3.2 %) |
0.67 (3.1 %) |
|
|
|
RSD |
|
0.39 (1.7 %) |
0.35 (1.5 %) |
|
|
|
|
|
|
|
|
|
|
|
|
Xxx |
- |
13.19 |
- |
13.26 |
|
|
|
|
Xyy |
- |
33.18 |
- |
33.15 |
|
|
|
|
Xzz |
|
46.37 |
|
46.40 |
|
|
|
|
ETA |
|
0.431 |
|
0.429 |
|
|
|
|
Øz,a |
|
52.14 |
|
52.14 |
|
|
|
|
Øa,n* |
|
53.97 |
|
53.97 |
|
|
|
|
Øz,n |
|
1.83 |
|
1.83 |
|
|
|
|
Øy,bi* |
|
0 |
|
0 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| |
|
|
|
|
|
|
|
|
|
Table 4. 33S nqcc's in t-2,3-Dimethylthiirane (MHz). Calculation was made on the rs structure with CH parameters given by MP2/6-311+G(d,p) partial optimization. |
|
| |
|
|
|
|
|
|
|
|
|
|
|
Calc [a] B3LYP/6-311G(3df,3p) model. |
|
|
|
|
Calc [b] B3LYP/TZV+(3df,3p) model. |
|
|
|
|
|
|
|
|
|
|
|
|
|
Calc. [a]
|
|
Calc. [b] |
|
Expt. [1] |
|
| |
|
|
|
|
|
|
|
|
|
Xaa |
|
9.16 |
|
9.13 |
|
8.3871(93) |
|
|
Xbb |
- |
33.22 |
- |
33.19 |
- |
32.3291(174) |
|
|
Xcc |
|
24.06 |
|
24.06 |
|
23.9420(174) |
|
|
|Xac| |
|
28.80 |
|
28.85 |
|
|
|
|
|
|
|
|
|
|
|
|
|
RMS |
|
0.69 (3.2 %) |
0.66 (3.0 %) |
|
|
|
RSD |
|
0.39 (1.7 %) |
0.35 (1.5 %) |
|
|
|
|
|
|
|
|
|
|
|
|
Xxx |
- |
13.14 |
- |
13.21 |
|
|
|
|
Xyy |
- |
33.22 |
- |
33.19 |
|
|
|
|
Xzz |
|
46.36 |
|
46.40 |
|
|
|
|
ETA |
|
0.433 |
|
0.431 |
|
|
|
|
Øz,a |
|
52.25 |
|
52.25 |
|
|
|
|
Øa,n* |
|
53.96 |
|
53.96 |
|
|
|
|
Øz,n |
|
1.71 |
|
1.71 |
|
|
|
|
Øy,bi* |
|
0 |
|
0 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Table 5. t-2,3-Dimethylthiirane. Heavy atom structure parameters, ro and rs [2] (Å and degrees). Complete structures are given here in Z-matrix format. |
| |
|
|
|
| Point Group: C2 |
|
ro |
rs |
|
|
|
|
|
C(4)C(2) |
1.509(6) |
1.514(3) |
| C(2)C(3) |
1.467(2) |
1.487(9) |
| SC(2,3) |
1.830(3) |
1.822(2) |
| C(4)C(2)C(3) |
120.93(13) |
120.70(30) |
| C(4)C(2)S |
118.02(32) |
117.83(17) |
| C(2)C(3)S |
66.02(13) |
66.26(10) |
| C(2)SC(3) |
47.96(25) |
47.49(7) |
| C(4)C(2)C(3)S |
109.44(20) |
109.39(17) |
| C(4)C(2)C(3)C(5) |
141.12(40) |
141.23(19) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
[1] J.-U.Grabow and H.Dreizler, Z.Naturforsch. 51a,1107(1996). |
|
|
[2] H.Hartwig and H.Dreizler, Z.Naturforsch. 51a,1099(1996). |
|
|
Related ... |
|
|
B.Kirchner, H.Huber, G.Steinebrunner, H.Dreizler, J.-U.Grabow, and I.Merke, Z.Naturforsch. 52a,297(1997).
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
