Phenanthridine |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Nitrogen
|
|
|
Nuclear
Quadrupole Coupling Constants |
|
|
in Phenanthridine
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Nitrogen nqcc's in phenanthridine were determined by McNaughton et al. [1]. |
|
|
|
|
|
|
|
|
|
|
|
|
Calculation of the 14N nqcc's in phenanthridine was made here on molecular structures derived by B3P86/6-31G(d,p) and B3LYP/6-311G(d,p)
optimizations. Calculated and experimental nqcc's are compared in
Table 1. Structure parameters are given in Table 2. Rotational constants are compared in Table 3. |
|
|
|
|
|
|
|
|
|
|
|
|
In Table 1, subscripts a,b,c refer to the
principal axes of the inertia tensor; x,y,z to the principal axes
of the nqcc tensor.
Ø (degrees) is the angle between its subscripted
parameters. ETA = (Xxx - Xyy)/Xzz. |
|
|
RMS is the root mean square
difference between calculated and experimental diagonal nqcc's (percentage of the
average of the magnitudes of the experimental nqcc's). RSD is the
calibration residual standard deviation of the B3PW91/6-311+G(df,pd) model for calculation of nitrogen nqcc's. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| |
|
|
|
|
|
|
|
|
|
Table 1. 14N nqcc's
in Phenanthridine (MHz). Calculation was made
on (1) B3P86/6-31G(d,p) and (2) B3LYP/6-311G(d,p) optimized structures. |
|
| |
|
|
|
|
|
|
|
|
|
|
|
Calc. (1)
|
|
Calc. (2) |
|
Expt. [1] |
|
| |
|
|
|
|
|
|
|
|
|
Xaa |
- |
0.559 |
- |
0.565 |
- |
0.6054(89) |
|
|
Xbb |
- |
2.636 |
- |
2.627 |
- |
2.5829(54) |
|
|
Xcc |
|
3.195 |
|
3.192 |
|
3.1883 |
|
|
|Xab| |
|
2.938 |
|
2.962 |
|
3.046(293) |
|
|
|
|
|
|
|
|
|
|
|
RMS |
|
0.041 (1.9 %) |
|
0.034 (1.6 %) |
|
|
|
|
RSD |
|
0.030 (1.3 %) |
|
0.030 (1.3 %) |
|
|
|
|
|
|
|
|
|
|
|
|
|
Xxx |
|
1.518 |
|
1.540 |
|
|
|
|
Xyy |
|
3.195 |
|
3.192 |
|
|
|
|
Xzz |
- |
4.713 |
- |
4.732 |
|
|
|
|
ETA |
|
0.356 |
|
0.349 |
|
|
|
|
Øz,a |
|
54.73 |
|
54.60 |
|
|
|
|
Øa,bi |
|
59.82 |
|
59.86 |
|
|
|
|
Øz,bi* |
|
5.09 |
|
5.26 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
* Angle between the principal z-axis of the nqcc tensor and the bisector ( bi ) of the CNC angle. |
|
|
The z-axis tilts 5.09o / 5.26o away from the external bisector and toward C(9). |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Table 2. Phenanthridine. NC bond
lengths and CNC angle (Å and degrees). Complete structure parameters are given here in Z-matrix format. |
| |
|
|
|
|
|
|
ropt (1) B3P86/6-31G(d,p) |
|
|
ropt (2) B3LYP/6-311G(d,p) |
| |
|
|
|
|
|
|
ropt (1) |
ropt (2) |
|
|
|
|
| C(7)N |
1.2976 |
1.2967 |
| NC(9) |
1.3789 |
1.3829 |
| C(7)NC(9) |
117.80 |
118.03 |
| |
|
|
| |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| |
|
|
|
|
| Table 3. Phenanthridine. Rotational Constants (MHz). Normal Species. |
| |
|
|
|
|
|
ropt (1) = B3P86/6-31G(d,p) optimization. |
|
ropt (2) = B3LYP/6-311G(d,p) optimization. |
|
|
|
|
|
|
|
Calc. ropt (1) |
Calc. ropt (2) |
Expt. [1] |
|
|
|
|
|
|
A |
1651.5 |
1648.4 |
1642.457218(32) |
|
B |
558.8 |
556.9 |
557.7346992(224) |
|
C |
417.5 |
416.2 |
416.5095420(174) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
[1] D.McNaughton, P.D.Godfrey,
R.D.Brown, S.Thornwirth, and J.-U.Grabow, Astrophys.J. 678,309(2008); Abstract 33, HRMS, 20th
Colloquium, Dijon, France, 2007; D.McNaughton, P.D.Godfrey,
R.D.Brown, and S.Thornwirth, PCCP 9,591(2007). |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
